How does a cascaded H-bridge converter-based battery energy storage system protect against lightning?
The lightning transients of cascaded H-bridge converter-based battery energy storage system (CHBC-BESS) are first studied. The reactor plays a key role in protecting the CHBC-BESS by reducing both the magnitude and steepness of lightning surge. The layout of CHBC-BESS within prefabricated cabins significantly influences the lightning transients.
How does Bess layout affect power supply overvoltage?
The influences of BESS layout schemes, lightning protection devices and line surge arresters (LSAs) are discussed. The results indicate that the surge originating from the 35 kV grid induces the highest overvoltage, with peak voltages of 496.54 kV at the grid side of the series reactor and 57.27 kV at the AC terminal of the CHBC-BESS.
Does CHBC-Bess have surge protection?
Though the reactor provides surge protection for CHBC-BESS, extreme conditions may still lead to a failure in the power conversion system (PCS). Additionally, overvoltage risks increase when the power modules (PMs) and battery clusters are dispersed; specifically, the peak voltage across AC terminals of submodule 1 (SM1) rises from 1.70 to 3.43 kV.
Why should I use multi-column parallel surge arresters at a 35 kV busbar?
To mitigate potential damage to the arresters from high lightning currents or multiple strikes, it is recommended to use multi-column parallel surge arresters at the 35 kV busbar. This configuration reduces the electrical and thermal stress on individual arresters, thereby enhancing their protection performance and overall reliability. 5.
How do you energize a high voltage power supply?
Attach the high-voltage power supply positive lead to J1 and the negative to J4. Connect an isolated probe to S1-HV– to measure the voltage across the capacitor as the capacitor charges. Connect an isolated probe to VDRV-VSSS to show the step of the drive pin. Close the enclosure and energize the high-voltage power supply.
How do you connect a 5V power supply to a circuit board?
Turn off the 5V power supplies leaving the cables attached. Placing the board in the enclosure, attach one lead of the precharge resistor to J2 and the other lead to J3. Attach the positive terminal of the capacitor to J3 and the negative terminal to J4. Attach the high-voltage power supply positive lead to J1 and the negative to J4.
