How do transfer switches work?
Transfer switches can transition loads between normal and emergency power sources in two basic ways: open or closed. The specific functions performed by a given load and the importance of those functions to safety or security play an important role in determining which kind of transition is required.
Do closed transition transfer switches include mechanical or electrical interlocking?
Closed transition transfer switches do not include mechanical nor electrical interlocking of sources. Since there is no gap between disconnecting and connecting sources, downstream loads receive continuous power throughout the transfer process.
What is a closed transition switch?
A closed transition is a “make before break” transfer, in that the transfer switch makes a connection to the new power source before breaking its connection to the old one. As there’s no gap between disconnection and connection, downstream loads receive continuous power throughout the transfer process. synchronized in phase, voltage, and frequency.
Can a transfer switch include a space heater?
Transfer switches can be configured to include space heaters for outdoor installations where condensation could occur. Transfer switches play a significant part in the power system as they are the last link between the power sources and the loads.
What is a closed-transition transfer switch?
Closed-transition transfer switches provide a “make-before-break” switching action and utilize a momentary paralleling of both sources (<100ms) during the transfer period, when both sources are available. Both sources must be synchronized (phase, voltage, and frequency) before momentary paralleling them (see Figure-09).
What is a transfer switch configuration?
The transfer switch configuration includes a utility feed and a generator set for normal and emergency power sources (see Figure-01). In this configuration two utility sources provide redundancy in the distribution system and allows for quick restoration of service to the load if one utility source fails.
